500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community

500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community

Large Image :  500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community

Product Details:
Place of Origin: China
Brand Name: weichai boduan
Model Number: 6M33D633E200
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $37,931.00/units >=1 units
Packaging Details: Box packaging
Contact Now

500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community

Description
Warranty: 3months-1year Rated Voltage: 230V, 400V
Rated Current: 900A Speed: 1500RPM, 1800RPM
Frequency: 50/60HZ Starting System: Auto Start
Type: Trailer Type, Silent Type, Container Type, Super Silent Type, Open Frame, Portable Type, Mobile Type, Canopy Type, Silent Weight: 2090kg
Cooling System Type: Water Cooling System Alternator: Marathon
Options: Automatic Transfer Switch Engine Type: Direction Injection
Product Name: Silent Speaker Unit Color: Customers' Request
Phase: 1 Phase/3 Phase ControllerControl Panel: Smargen
Rated Power: 500KW

Details Images
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 0
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 1
500KW Weichai Boduan diesel generator set
550KW Boduan diesel generator set parameters 1、 Technical specifications (1) Model: 550GF Common power (KW): 550 Backup power (KW): 605 Frequency: 50Hz Output voltage: 400/230V Speed: 1500rpm Power factor: COS Φ= 0.8 (lag) Fuel consumption (g/Kw * h): 210 (recommended to use No. 0 diesel) Maximum output current (A): 990 Number of phases/lines: three-phase four wire Noise LP7m: 105dB External dimensions (mm): 3100 * 1300 * 1650 (external dimensions are subject to the actual product) Weight: 3600Kg (weight based on actual product) (2) Diesel engine: Brand: Boduan Origin: Boduan (Weifang) Power Co., Ltd Model: 6M33D605E200 Cooling start: closed water cooling Starting method: 24V DC power start Number of cylinders: 6 Displacement: 19.6L Compression ratio: 15:1 Fuel supply method: direct injection Air intake method: turbocharging and intercooling Cylinder arrangement: inline Intercooling method: water cooling Fuel model: Domestic 0 # light diesel Speed regulation method: electronic speed regulation Diesel engine coolant capacity: 41.63L Diesel oil pan capacity: 60.5L Oil model: WD/40 Cylinder diameter/stroke: 150/185mm External dimensions (mm): 2254 * 1138 * 1528 Net weight of diesel engine (KG): 2090 (3) Generator: Brand: Shanghai Stanford Origin: Jiangsu Model: STF-500 Material: Pure copper Insulation level: H Voltage control mode: AVR Voltage: ≤ 4% Rated voltage (V): 400/230 Protection level: IP23 Frequency: 50Hz Phase number/wiring: three-phase four wire/Y-shaped winding connection Frequency adjustment rate (%): ≤ ± 0.5 (steady-state)+10~-7 (transient) Voltage adjustment rate (%): ≤ ± 0.5 (steady-state)+20~-15 (transient) Frequency fluctuation rate (%): ≤ ± 0.5 Voltage fluctuation rate (%): ≤ ± 0.5
Products Description
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 2
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 3
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 4
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 5
Product packaging
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 6
Our Factory
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 7
Manufacturing Technique
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 8
Certifications
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 9
Recommend Products
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 10
500KW Weichai Boduan Diesel Generator Set Your Go-To Backup Power Supply for Community 11
