1、 Technical specifications (1) Model: 700GF Common power (KW): 700 Backup power (KW): 792 Frequency: 50Hz Output voltage: 400/230V Speed: 1500rpm Power factor: COS Φ= 0.8 (lag) Fuel consumption (g/Kw * h): 210 (recommended to use No. 0 diesel) Output current (A): 1260 Number of phases/lines: three-phase four wire Noise LP7m: 108db External dimensions (mm): 4000 * 1700 * 2100 (external dimensions are subject to the actual product) Weight: 7300Kg (weight based on actual product) (2) Diesel engine: Brand: Boduan Origin: Boduan (Weifang) Power Co., Ltd Model: 12M26D792E200 Cooling start: closed water cooling Starting method: 24V DC power start Number of cylinders: 12 Cylinder arrangement: V-shaped Displacement: 31.8L Compression ratio: 15:1 Diesel engine cylinder diameter/stroke mm: 150/150 Diesel engine coolant capacity: 80L Diesel oil pan capacity: 113L Fuel supply method: direct injection Air intake method: turbocharging and intercooling Intercooling method: water cooling Fuel model: Domestic 0 # light diesel Speed regulation method: electronic speed regulation Oil model: WD/40 Net weight of diesel engine (Kg): 2910 External dimensions (mm): 2615 * 1525 * 1760
