Diesel generator set data Model 150GF Unit Power (KVA/KW) 187.5/150 Output voltage (V) 400/230 Rated output current (A) 270 Wiring method: three-phase four wire power factor 0.8 (lagging) Starting method 24V DC starting frequency (Hz) 50 Unit weight (kg) 1600 Unit size (length × wide × High) 2500 × nine hundred and fifty × 1500mm Diesel engine data Manufacturer Weifang Model R6113ZLD Rated speed (Rpm) 1500 engine power (KW) 155 Number of cylinders 6, arrangement of cylinders inline Cylinder diameter × Travel (mm) 113 × 125 displacement (L) 7.52 Air intake method, turbocharging, intercooling, compression ratio 16:1 Fuel consumption of China's 0 # light diesel load (G/KW. h) 218 Lubricating oil specification 15W/40CD Lubricating oil consumption (L/h) 0.5% Fuel consumption Starting method: Electric starting coolant capacity (L) 68 The engine cooling method meets the ambient temperature of 40 ℃. The radiator is belt driven and the cooling fan is equipped with a fan cover Generator data Manufacturer Fujian or Shanghai model STC-150 Power (KVA/KW) 187.5/150, protection level IP21 The steady-state voltage adjustment rate of insulation level F is better than ± 1% No load voltage adjustment range ≥ ± 5% Voltage control mode AVR Efficiency (%) 80
